Seiko SPT510 50PL

Description:
As an extension product of the SPT510 series of products, the Seiko SPT510-50PL Printhead is positioned for users of high-volume advertising inkjet processing. It can provide stable, reliable, and highly flexible inkjet solutions to produce eye-catching promotional advertisements.
Fully equipped with 510 active nozzles for high-resolution (720dpi) and high-speed (50 pl) printing and steel-plate protection for a longer life, inheriting the excellent inkjet stability, reliable jet life, and high-quality image output of the SPT510-35PL printhead.

pecifications:
Technology: Drop-on-demand Piezo Electric
Active Nozzles: 510
Native Resolution: 180 dpi
Max Resolution: 720 dpi
Printing Speed: 4.2 m/s
Print Width: 71.8 mm
Drop Volume: 50 pl
Firing Frequency: 6-8 kHz
Ink Type: Solvent, UV, and oil-based inks
Remarks: Original

Application: work for all Chinese printers like Sid triton Gongzheng ZHONGYE:ZY3200,ZY2500,ZY1800,ZY5300,ZY-UVB,ZY-UVC,ZY-UVA (ZY-SK3206,SK3204,SK3208,SK3212,SK2504,SK2506,SK2508,SK2512 etc) sereis con cabezales spt510/35PL
Infiniti/Challenger/Pheaton Serie: FY-3208R ,FY-3208H,FY-3208HA,FY-3206HF,UD3208 UD3206 etc
Crystaljet 3000 ,Crystaljet 4000,Crystaljet 5000,Crystaljet 6000,Crystaljet 9000 ,Crystaljet UV,Iconteck,Meitu,Wer,etc

Compatible Ink for this head: Solvent ink,UV ink,
